Product Details (12)
Dimensions
Width: 110 mm (4.22 in), Height: 115 mm (4.52 in), Depth: 44 mm (1.7 in)
Connections
2 x SeaTalkngconnections (compliant with SeaTalk), Transducer connections
Relative humidity
Max. 93%
Waterproof rating
IPx6
Storage temperature
-30 °C to +70 °C (-22 °F to 158 °F)
Operating temperature
-20 °C to +55 °C (-13 °F to 131 °F)
Standards
Europe 2004/108/EC
Current (typical / max)
45-65 mA (display only) / 200 mA maximum (transducer connected)
Nominal supply voltage
12 V dc
Operating voltage range
10 V dc to 16 V dc
Power consumption
< 1 W typical (display only), 2.4 W maximum (transducer connected)
LEN (NMEA 2000 Load Equivalency Number)
4
