Product Details (15)
Relative humidity
Up to 95%
Waterproof rating
IPx6, IPx7
Storage temperature
-30°C to +70°C (-22°F to 158°F)
Operating temperature
0°C to 55°C (32°F to 131°F)
Dimensions
Height: 162 mm (6.4 in), Width: 225 mm (8.9 in), Depth: 72 mm (2.8 in)
Weight
0.6 kg (1.32 lbs)
Standards
EN 60945:2002, EMC Directive 2014/30/EU, Australia and New Zealand: C-Tick, Compliance Level 2
Power consumption
5.6 W (maximum)
Fuse rating
5 A
Nominal supply voltage
12 V dc / 24 V dc
Operating voltage range
10.8 V dc to 31.2 V dc
Current
1 A peak
Depth range
Up to 183 m (600 ft) (Range performance is dependent on many factors, including water quality, transducer installation, and reflectivity of targets and structure.)
Beam coverage
Port and starboard-facing - wide (port / starboard) and thin (fore / aft)
Channels
CHIRP port and starboard
